Juniper ACX1000 Hardware Guide

Figure 13: Front Panel of the DC-Powered ACX1100 Router
g017842
0/0/0
0/0/1 0/0/2 0/0/3
0/0/4
0/0/5 0/0/6 0/0/7
GE
0/1/0
0/1/1
0/1/2 0/1/3
0/1/0
0/1/1 0/1/2 0/1/3
CONSOLE/AUX
COMBO PORTS
12
8 7
5 643
91011
1 2
7—1— Combination Gigabit Ethernet SFP portsDC terminals
8—2— External clocking portsManagement Ethernet port
9—3— Console or auxiliary portAlarm contact port
10—4— USB port
Gigabit Ethernet (GE) ports
11—5—
System (SYS) LED
Combination Gigabit Ethernet RJ-45 ports
12—6— Grounding terminalsESD point
Related
Documentation
ACX1000 and ACX1100 Universal Access Router Overview on page 3•
• ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5
• LEDs on ACX1000 and ACX1100 Routers on page 35
Uplink Ports on ACX1000 and ACX1100 Routers
Unless otherwise specified, the information about uplink ports applies to both ACX1000
and ACX1100 routers.
TIP: You can find information about the pluggable transceivers supported
on your Juniper Networks device by using the Hardware Compatibility Tool.
In addition to transceiver and connector type, the optical and cable
characteristics—where applicable—are documented for each transceiver.
The Hardware Compatibility Tool allows you to search by product, displaying
all the transceivers supported on that device, or category, displaying all the
transceivers by interface speed or type. The Hardware Compatibility Tool is
located at https://pathfinder.juniper.net/hct/.
The list of supported transceivers for the ACX1000 is located at
https://pathfinder.juniper.net/hct/product/#prd=ACX1000. The list of supported
transceivers for the ACX1100 is located at
https://pathfinder.juniper.net/hct/product/#prd=ACX1100.
•
T1/E1 Ports on page 33
•
Gigabit Ethernet RJ-45 Ports on page 33
•
Gigabit Ethernet SFP Ports on page 34
Copyright © 2017, Juniper Networks, Inc.32
ACX1000 and ACX1100 Universal Access Router Hardware Guide
