CHAPTER 7
Mounting Requirements
•
Cabinet Requirements for ACX1000 and ACX1100 Routers on page 51
•
Rack Requirements for ACX1000 and ACX1100 Routers on page 52
Cabinet Requirements for ACX1000 and ACX1100 Routers
You can mount the router in a cabinet that contains a 19-in. (48.3 cm) rack.
Cabinet requirements consist of:
•
Cabinet size
•
Clearance requirements
•
Cabinet airflow requirements
Table 18 on page 51 provides the cabinet requirements and specifications for the router.
Table 18: Cabinet Requirements and Specifications for the ACX1000 and ACX1100 Router
GuidelinesCabinet Requirement
•
You can mount the router in a cabinet that contains a 19-in.
(48.3 cm) rack as defined in Cabinets, Racks, Panels, and
Associated Equipment (document number EIA-310–D)
published by the Electronics Industry Association
(http://www.eia.org).
NOTE: The cabinet must meet the strength requirements
to support the weight of the router.
•
The minimum cabinet size must be able to accommodate
the maximum external dimensions of the router.
Cabinet size
•
The outer edges of the mounting brackets extend the width
of the chassis to 19 in. (48.3 cm).
•
The minimum total clearance inside the cabinet is 30 in.
(76.2 cm) between the inside of the front door and the inside
of the rear door.
Cabinet clearance
51Copyright © 2017, Juniper Networks, Inc.
