External Clocking Ports Specifications on the ACX1000 and ACX1100 Router
The external clocking port on the ACX1000 and ACX1100 router contains four SMB
connectors that support 10 MHz GPS and 1 pulse-per-second (PPS) signals. These signals
are internally isolated and have surge protection. Use a Molex 50-ohm SMB connector
or equivalent (not provided) to connect to the external clocking ports.
