CHAPTER 3
Cooling System Components and
Descriptions
•
Cooling System and Airflow in an ACX1000 and ACX1100 Router on page 39
Cooling System and Airflow in an ACX1000 and ACX1100 Router
The router does not contain fans and is passively cooled by the heatsinks (see
Figure 14 on page 39).
Temperature sensors in the chassis monitor the temperature within the chassis. If the
temperature inside the chassis rises above the threshold, the router shuts down
automatically.
Figure 14: Cooling System and Airflow in an ACX1000 and ACX1100 Router
g006417
Front
Rear
Related
Documentation
• Site Preparation Checklist for ACX1000 and ACX1100 Routers on page 45
• Rack Requirements for ACX1000 and ACX1100 Routers on page 52
• Cabinet Requirements for ACX1000 and ACX1100 Routers on page 51
