Page #121 background imageLoading...
Page #121 background image
CAUTION: After removing a transceiver from the chassis, wait at least 30 seconds
before reinserting it or inserting a transceiver into a different slot.
SEE ALSO
Front Panel of an ACX2000 Router | 47
Front Panel of an ACX2100 Router | 48
Uplink Ports on ACX2000 and ACX2100 Routers | 50
Installing a Transceiver in the ACX2000 or ACX2100
To install a transceiver:
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to an ESD point.
2. Take each transceiver to be installed out of its electrostatic bag, and identify the slot on the component
where it will be installed.
3. Verify that each transceiver is covered by a rubber safety cap. If it is not, cover the transceiver with a
safety cap.
4. Carefully align the transceiver with the slots in the component. The connectors should face the
component.
5. Slide the transceiver until the connector is seated in the component slot. If you are unable to fully insert
the transceiver, make sure the connector is facing the right way.
6. Close the ejector handle of the transceiver.
7. Remove the rubber safety cap from the transceiver and the end of the cable. Insert the cable into the
transceiver.
121
