Table 3: CLI Equivalents of Terms Used in Documentation for ACX2000 Routers (continued)
Additional InformationItem in Documentation
Value (as
displayed in
the CLI)
Description (as
displayed in the
CLI)
Hardware
Item (as
displayed
in the CLI)
“Cooling System and Airflow in
an ACX2000 and ACX2100
Router” on page 60
Fan–Fan
NOTE: ACX2000
routers are fanless
models.
Fan
Figure 5: ACX2000 Interface Port Mapping
ACX2000
MGMT
SYS 0 1
CONSOLE/AUX
ALARM
1PPS
10MHz
IN OUT
IN OUT
T1/E1
0/0/4
0/0/12
0/0/5
0/0/13
0/0/6
0/0/14
0/0/7
0/0/15
0/0/0
0/0/8
0/0/1
0/0/9
0/0/2
0/0/10
0/0/3
0/0/11
0/1/0
0/1/4
0/1/1
0/1/5
0/1/2
0/1/6
0/1/3 POE
0/1/7 POE
GE
0/2/0
0/2/1 0/3/0 0/3/1
g006414
EXT REF CLK IN
GE
XE
FPC 0, PIC 2
GE 0/2/0-0/2/1
FPC 0, PIC 0
T1/E1 0/0/0-0/0/15
FPC 0, PIC 1
GE 0/1/0-0/1/7
FPC 0, PIC 3
XE 0/3/0-0/3/1
ACX2100 Hardware and CLI Terminology Mapping
Table 4 on page 22 describes the hardware terms used in ACX2100 router documentation and the
corresponding terms used in the Junos OS command line interface (CLI). Figure 6 on page 24 shows the
port locations of the interfaces.
Table 4: CLI Equivalents of Terms Used in Documentation for ACX2100 Routers
Additional InformationItem in Documentation
Value (as
displayed in the
CLI)
Description (as
displayed in the
CLI)
Hardware
Item (as
displayed
in the CLI)
“Chassis Physical Specifications
for ACX2000 and ACX2100
Routers” on page 72
Router chassis–ACX2100Chassis
Interface Naming Conventions
Used in the Junos OS Operational
Commands
The router does not have
actual FPCs. In this case,
FPC refers to the router
itself.
n is a value in the
range of 0–1.
Abbreviated name of
the Flexible PIC
Concentrator (FPC)
FPC (n)
22
