Table 4: CLI Equivalents of Terms Used in Documentation for ACX2100 Routers (continued)
Additional InformationItem in Documentation
Value (as
displayed in the
CLI)
Description (as
displayed in the
CLI)
Hardware
Item (as
displayed
in the CLI)
Interface Naming Conventions
Used in the Junos OS Operational
Commands
The router does not have
actual PIC devices; see
entries for PIC 0 through
PIC 3 for the equivalent
item on the router.
n is a value in the
range of 0–3.
Abbreviated name of
the Physical
Interface Card (PIC)
PIC (n)
“ACX2000 and ACX2100
Universal Metro Router
Overview” on page 17
Built-in network ports on
the front panel of the
router
PIC 0 on FPC 016x T1/E1 (RJ-48)
“ACX2000 and ACX2100
Universal Metro Router
Overview” on page 17
Built-in network ports on
the front panel of the
router
PIC 0 on FPC 14x 1GE (RJ-45)
“ACX2000 and ACX2100
Universal Metro Router
Overview” on page 17
Built-in uplink ports on
the front panel of the
router
PIC 1 on FPC 1One of the following:
•
4x 1GE (RJ-45)
•
4x 1GE (SFP)
“ACX2000 and ACX2100
Universal Metro Router
Overview” on page 17
Built-in uplink ports on
the front panel of the
router
PIC 2 on FPC 12x 1GE (SFP)
“ACX2000 and ACX2100
Universal Metro Router
Overview” on page 17
Built-in uplink ports on
the front panel of the
router
PIC 3 on FPC 12x 10GE (SFP+)
“Uplink Ports on ACX2000 and
ACX2100 Routers” on page 50
Optical transceiversn is a value
equivalent to the
number of the
port in which the
transceiver is
installed.
Abbreviated name of
the transceiver
Xcvr (n)
“ACX2000 and ACX2100 Power
Overview” on page 62
AC or DC power supplyValue of n is
always 0.
Built-in power
supply
Power
supply (n)
