Juniper ACX2000 Hardware Guide

SEE ALSO
Management Port Connector Pinout Information for ACX Series Routers | 87
Installing an ACX2000 and ACX2100 Management Ethernet Cable
To install a serial cable connected to a management device:
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to an ESD point.
2. Plug one end of the replacement cable into the appropriate MGMT port.
3. Plug the other end of the cable into the network device.
SEE ALSO
Management Port Connector Pinout Information for ACX Series Routers | 87
Replacing an ACX2000 or ACX2100 Console or Auxiliary Cable
1.
Removing an ACX2000 or ACX2100 Console or Auxiliary Cable | 123
2.
Installing an ACX2000 or ACX2100 Console or Auxiliary Cable | 124
Removing an ACX2000 or ACX2100 Console or Auxiliary Cable
To remove a serial cable connected to a console or auxiliary device:
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to an ESD point.
2. Press the tab on the connector, and pull the connector straight out of the CONSOLE/AUX port.
Figure 30 on page 124 shows the connector.
3. Disconnect the cable from the console or auxiliary device.
123
