Table 33: Parts List for an ACX2000 and ACX2100 Router (continued)
QuantityComponent
1Quick Start installation instructions
1Juniper Networks Product Warranty
1End User License Agreement
NOTE: You must provide additional mounting screws if needed that are appropriate for your
rack or cabinet to mount the chassis on a rack or a cabinet.
SEE ALSO
ACX2000 and ACX2100 Universal Metro Router Overview | 17
Installing the ACX2000 or ACX2100 Mounting Brackets
To attach the mounting brackets, you need the following tools:
•
Phillips (+) screwdriver, number 2
Two mounting brackets for front or rear mounting ship with the router (see Figure 18 on page 97 and
Figure 19 on page 97).
To attach both mounting brackets to either the front or rear of the chassis:
1. Align the bracket with the two sets of mounting holes.
2. Insert the four screws at the top and bottom of the bracket, and tighten each partially.
3. Tighten the four screws completely.
4. Repeat the procedure for the other bracket.
