CAUTION: Do not leave a fiber-optic transceiver uncovered except when
inserting or removing cable. The safety cap keeps the port clean and prevents
accidental exposure to laser light.
5. Arrange the cable in the cable management system to prevent it from dislodging or developing stress
points. Secure the cable so that it is not supporting its own weight as it hangs to the floor. Place excess
cable out of the way in a neatly coiled loop in the cable management system. Placing fasteners on the
loop helps to maintain its shape.
CAUTION: Avoid bending fiber-optic cable beyond its minimum bend radius.
An arc smaller than a few inches in diameter can damage the cable and cause
problems that are difficult to diagnose.
6. Pull the ejector latch to the extreme end away from the CFP2 transceiver faceplate to unseat the CFP2
transceiver from the device. Pull the CFP2 transceiver out of the device and place it on the antistatic
mat or in the electrostatic bag.
NOTE: You cannot remove the transceiver until you move the ejector latch to the extreme
end.
Installing a CFP2 Transceiver
To install a replacement CFP2:
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
2. Verify that a rubber safety cap covers the CFP2 transceiver, installing one if necessary.
3. Orient the CFP2 over the port in the device so that the connector end will enter the slot first and the
CFP2 connector faces the appropriate direction.
4. Slide the CFP2 into the slot. If there is resistance, remove the CFP2 and flip it so that the connector
faces the other direction.
