Juniper ACX5448-D - Port Panel of an ACX5448-M Router

LED Behavior for CFP2 Ports
Table 7 on page 36 summarizes the LED port behavior for CFP2 DCO ports.
Table 7: LED behavior for CFP2 ports
Second et-
traffic
First et-
traffic
Second et-
port status
First et-
port status
DescriptionStateColorMode
OffOffUpUpIndicates that the port is up
and the port speed is 200
Gbps but there is no traffic
passing.
OnGreen200G
OnOnUpUpIndicates that the port speed
is 200 Gbps, and there is some
activity.
FlashingGreen200G
OffOffDownUpIndicates that the port is up
and the port speed is 100
Gbps but there is no traffic
passing.
OnAmber100G
OffOffUpDown
OffOnDownUpIndicates that the port is up
and the port speed is 100
Gbps and there is some
activity.
FlashingAmber100G
OnOffUpDown
OffOnUpUp
OnOffUpUp
There is no link on the port.OffUnlit
NOTE: The first et- interface in Table 7 on page 36 refers to the et-0/2/0 interface (port 38) or
the et-0/2/2 interface (port 39). Similarly, the second et interface refers to the et-0/2/1 interface
(port 38) or the et-0/2/3 interface (port 39).
Port Panel of an ACX5448-M Router
The port panel of the ACX5448-M router has the following port configurations:
•
Forty-four 10-Gigabit or 1-Gigabit Ethernet ports (0 through 43) that operate at 10-Gbps speed with
SFP+ transceivers or at 1-Gbps speed when you use SFP optics.
