Management Port LEDs on ACX5400 Routers
The management ports (labeled MGMT) for 10/100/1000BASE-T connections on ACX5400 routers have
two LEDs that indicate link status and link activity (see callout 3 and 4 in Figure 25 on page 40). The right
LED indicates status; the left LED indicates link activity.
Figure 25: Management Port LEDs on an ACX5448 Router
g100119
1 2
34
Figure 26: Management Port LEDs on an ACX5448-D Router
g100521
1 2
34
