Connect ACX5448, ACX5448-D, and ACX5448-M to
Power
IN THIS SECTION
Connect Earth Ground to ACX5400 Routers | 95
Connect AC Power to an ACX5400 Router | 98
Connect DC Power to an ACX5400 Router | 102
Connect Earth Ground to ACX5400 Routers
To meet safety and electromagnetic interference (EMI) requirements and to ensure proper operation, you
must ground the router properly before connecting power.
Figure 57 on page 95, Figure 58 on page 95, and Figure 59 on page 96 show the grounding points on
ACX5400 routers.
Figure 57: Grounding Points on the ACX5448 Router
Figure 58: Grounding Points on the ACX5448-D Router
95
