Juniper SRX320 Hardware Guide

SRX320 Services Gateway CLI and J-Web Access
The SRX320 Services Gateway runs the Junos operating system (Junos OS). You can
use two user interfaces to monitor, configure, troubleshoot, and manage the services
gateway:
•
J-Web interface—A Web-based graphical interface that allows you to operate the
services gateway without commands.
•
Junos OS command-line interface (CLI)—Juniper Networks command shell that runs
on top of a UNIX-based operating system kernel. The CLI is a straightforward command
interface. On a single line, you type commands that are executed when you press the
Enter key. The CLI provides command help and command completion.
In addition, you can also use Junos Space Security Director to define and manage security
policies on the services gateway.
Related
Documentation
• SRX320 Services Gateway Description on page 3
• SRX320 Services Gateway Chassis Overview on page 5
Copyright © 2016, Juniper Networks, Inc.4
SRX320 Services Gateway Hardware Guide

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
