CHAPTER 2
Chassis Description
•
SRX320 Services Gateway Chassis Overview on page 5
•
Understanding the SRX320 Services Gateway Front Panel on page 5
•
Understanding the SRX320 Services Gateway Back Panel on page 8
SRX320 Services Gateway Chassis Overview
The SRX320 Services Gateway chassis measures 1.73 in. high, 11.81 in. wide, and 7.52 in.
deep. The PoE model weighs 3.4 lb. and the non-PoE model weighs 3.28 lb.
CAUTION: Before removingor installing components of afunctioning services
gateway, attach an electrostatic discharge (ESD) strap to an ESD point and
place the other end of the strap around your bare wrist. Failure to use an ESD
strap could result in damage to the device.
The services gateway must be connected to earth ground during normal operation. The
protective earthing terminal on the rear of the chassis is provided to connect the services
gateway to ground.
Related
Documentation
Understanding the SRX320 Services Gateway Front Panel on page 5•
• Understanding the SRX320 Services Gateway Back Panel on page 8
Understanding the SRX320 Services Gateway Front Panel
Figure 1 on page 6 shows the front panel of the SRX320 Services Gateway.
