Juniper SRX320 Hardware Guide

admin@device# commit
19. When you have finished configuring the services gateway, exit configuration mode.
[edit]
admin@device# exit
admin@device>
Related
Documentation
Configuring the SRX320 Services Gateway Using the J-Web Setup Wizard on page 75•
Verifying Settings for the SRX320 Services Gateway
Access http://www.juniper.net to verify connectivity. If the page does not load, perform
the following checks to see if you can identify the problem:
•
Check if the cable connecting the ISP-supplied device to the SRX Series device is firmly
seated.
•
Use the CLI ping command to verify that the services gateway can be accessed from
the management device.
•
Check if the management device has an IP address in the 192.168.1.0/24 subnetwork.
•
Clear the browser cache on the management device.
After you complete these steps, the device can pass traffic from any trust port to the
untrust port. You can connect other devices to the SRX Series device.
Related
Documentation
• Configuring the SRX320 Services Gateway Using the CLI on page 79
• Configuring the SRX320 Services Gateway Using the J-Web Setup Wizard on page 75
81Copyright © 2016, Juniper Networks, Inc.
Chapter 18: Performing the Initial Configuration

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
