Juniper SRX320 Hardware Guide

Connecting the SRX320 Services Gateway to the Building Structure
Always secure the rack in which you are installing the services gateway to the structure
of the building. If your geographical area is subject to earthquakes, bolt the rack to the
floor. For maximum stability, also secure the rack to ceiling brackets.
Related
Documentation
• Preparing the SRX320 Services Gateway for Rack-Mount Installation on page 49
51Copyright © 2016, Juniper Networks, Inc.
Chapter 13: Installing the Rack Mounting Hardware

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
