Construction and Function
Operating Modes
4.6 Operating Modes
The unit provides the following ventilation functions.
Filters room air The secondary air drawn from the room passes through the
lterandiscleanedinlinewiththeltergrade(G2/F5/F7).
Heats room air Secondaryairpassesthroughtheheatexchangerlledwith
LPHW. Depending on the water temperature, the secondary air
is heated up and fed back into the room.
Cools room air Secondaryairpassesthroughtheheatexchangerlledwith
CHW. Depending on the water temperature, the secondary air
is cooled and fed back into the room.
Dehumidiesroomair If secondary air with a high relative humidity is cooled at a
lowerwatertemperature,thesecondaryairdehumidieson
the heat exchanger. The „dried“ air is then fed back into the
room.
Sekundärluft
Fig. 15: Operation (diagram)
Room
Secondary air
