Operation
Electrical wiring
6.15 Electrical Wiring
Only allow qualied electricians to perform
electrical work.
Further connections, for instance to building
control systems or external controllers, may
be necessary. Refer to the manufacturer‘s
literature in this respect
  Personnel:  Installation personnel
Qualiedelectrician
Protective protective  Safety shoes
  equipment:  Protective gloves
 Workwear
• Wire the unit in accordance with the enclosed wiring diagram.
• Only wire the unit in accordance with currently applicable VDE and
EN guidelines, as well as Technical Wiring Regulations stipulated by
the regional energy supply companies.
• Only connect the unit to fixed cables.
Important note: Provide an all-pole mains separator in the wiring
on site that can be reliably secured to avoid the system being
reconnected (e.g. a lockable switch with a contact opening of at
least 3 mm up to a rated voltage of 480 V).
No protective measures are indicated in the Kampmann wiring
diagrams. These must be provided additionally when installing
the system and when connecting the units in accordance with
VDE 0100 (NFPA70) and the regulations of each of the respective
energy supply companies.
Cabling
Ask a qualied electrical to determine the type of cable and
cross-sections. The cable cross sections are basically dependent on
the safety of the cable length and the wiring capacity of the electric
motors on site .
