6 Installation and Connection
6.1 Requirements Governing the Installation Site
Only install and assemble the unit if the following conditions
aremet:
The installation site is level and can bear the weight of the
unit (
Chapter 3 „Technical Data“ on page 15 ff).
The load-proof and vibration-free position of the unit is
guaranteed (possibly call in the services of an architect or
structural engineer, also in connection with openings to be
made through walls and ceilings).
Comply with the minimum clearances from the unit to the
wall/ceiling/oor(seepage39f).
Ensurethattheairowcancirculatefreely.
Make sure that drilling positions for installing the unit are
free from electrical wiring or pipes.
Provideforadequatespaceforoorandreturnwater
connections on site (
Chapter 3 „Technical Data“ on page 15 ff.)
Ensure that the unit can be installed without mechanical
torsion or tension when installed.
Ensure that the unit can be installed without mechanical
torsion or tension when installed. There is a power supply on
site (
Chapter 3 „Technical Data“ on page 15 ff.).
6.2 Minimum Clearances
The following minimum clearances have to be allowed for
wheninstallingthebasicunit:
1)
Theclearanceisprovidedbyttingthesidepanelsonunitswithfree-standing
casing.
Provide adequate inspection openings for all
arrangements in order to ensure access to the
unit and all water-side and electrical
connections.
model
Minimum distance to resistance
on site [mm]
left/right up below
mode basic unit wall-mounted without casing 165 150 100
mode basic unit wall-standing without casing 165 150 143
mode basic unit free-standing without casing 165 150 140
mode basic unit ceiling without casing 165 - 160
mode basic unit wall-mounted with casing 50 200 100
mode basic unit wall-standing with casing 50 200 0
mode basic unit free-standing with casin 50 200 0
mode basic unit ceiling with casing 50 - 0
