4 Imaging programs
Wide arch: Magnification 1.3
Used when the patient has a wider than normal dental arch.
Exposure settings for Wide arch program
100 VAC 66 kV/ 5 mA/ 43
mGycm
2
66 kV/ 8 mA/ 69
mGycm
2
66 kV/ 10 mA/ 87
mGycm
2
70 kV/ 12.5 mA/
122 mGycm
2
230 VAC 66 kV/ 5 mA/ 43
mGycm
2
66 kV/ 8 mA/ 69
mGycm
2
66 kV/ 10 mA/ 87
mGycm
2
70 kV/ 12.5 mA/
122 mGycm
2
Lateral TMJ: Magnification 1.23
