4 Imaging programs
Reconstruction with MAR is unavailable for the last captured image if the last taken
image is panoramic or cephalometric. “Retrieve With MAR” button is not visible.
NOTICE! Only the last taken x-ray image is saved in the unit, until a new patient
is selected or the power is switched off. This image data is used in the retrieve
procedure.
4.14 Exposure settings for 3D imaging
Exposure settings for 3D programs, small panel (default values)
NOTICE! Voltage setting is always 90kV with the unit 3D modality.
FOV Resolution Exposure
time
Scan
time
Voxel
size
(µm)
Default
mA
mAs DAP
(mGycm2)
Low Dose 1,2 s 11 s 290 3.2 3.8 32
Std Res 2,3 s 15,6 s 200 10 23 184
High Res 6,1 s 11,5 s 133 8 48.8 385
61 x 41
mm
Endo Res 6,1 s 11,5 s 85 10 61 476
Low Dose 2,4 s 21,1 s 330 3.2 7.7 66
Std Res 4,9 s 21,1 s 300 10 49 372
61 x 78
mm
High Res 12,6 s 21,0 s 200 6.3 79.4 619
40 ORTHOPANTOMOGRAPH
™
OP 3D Pro
