2 Introduction
2 Introduction
2.1 ORTHOPANTOMOGRAPH
™
OP 3D Pro
The ORTHOPANTOMOGRAPH
™
OP 3D Pro (hereafter called "unit") is a dental X-ray
system for producing high quality digital images of dentition, TM-joints and skull. In
order to take images with the unit you need a suitable PC hardware connected to the
unit and CLINIVIEW
™
software (or suitable third party software via TWAIN driver) to
capture and manage images. The unit performs the following procedures:
Panoramic
● Standard panoramic
● Pediatric panoramic (reduced width and height)
● Wide arch panoramic
● Bitewing
● TMJ, posterior-anterior (PA) projection
● TMJ, lateral projection
● Maxillary sinus
● Ortho Zone enhanced panoramic
● Orthogonal panoramic
Cephalometric (optional)
● Cephalometric lateral projection
● Cephalometric pediatric lateral projection
● Cephalometric postero-anterior (PA) projection
● Reverse Towne projection
● Waters view
● Carpus program (optional) (Not available in USA and Canada)
Small panel 3D (optional) H x W
● 61 x 41 mm Field of View
● 61 x 78 mm Field of View
Medium panel 3D, H x W (optional)
● 50 x 50 mm Field of View
● 61 x 78 mm Field of View
● 78 x 78 mm Field of View
● 78 x 150 mm Field of View
● 130 x 150 mm Field of View (optional)
NOTICE!
The FOV heights are maximum values measured at the center of the FOV, the
measured heights at the edges of the FOV are smaller.
ORTHOPANTOMOGRAPH
™
OP 3D Pro 7
