4 Imaging programs
Maxillary Sinus: Magnification 1.3
Mesial 10 mm Start Distal 10 mm
Maxillary Sinus program produces a pan - tomographic
layer through the posterior maxillary sinus. The layer
is flatter than the standard panoramic programs and is
moved 18 mm backward. These images are helpful in
visualizing the mid and posterior maxillary sinus.
Exposure settings for Maxillary Sinus program
100 VAC 66kV/ 6.3mA/ 34
mGycm
2
66 kV/ 10 mA/ 54
mGycm
2
66 kV/ 12.5 mA/
68 mGycm
2
73 kV/ 12.5 mA/
85 mGycm
2
230 VAC 66kV/ 6.3mA/ 34
mGycm
2
66 kV/ 10 mA/ 54
mGycm
2
66 kV/ 12.5 mA/
68 mGycm
2
73 kV/ 12.5 mA/
85 mGycm
2
Bitewing: Magnification 1.3
26 ORTHOPANTOMOGRAPH
™
OP 3D Pro
