6 Using the unit
4. Adjust the height of the Frankfort-Horizontal plane (FH) light so that it goes through
the patients Porion and Orbitale.
NOTICE! The portrayed light line is a horizontal reference line.
5. Tilt the nasion support down and slide it towards patient’s nasion.
