10 Technical data
Positioning lights
Panoramic, TMJ & Maxillary Sinus
Programs
Cephalostat FH laser light
3D imaging programs
laser light
(CLASS 1 LASER PRODUCT)
max output 100µW
Warning symbols are placed next to the laser
lights and the label describing the laser light
classification is placed inside the carriage side
cabinet. USA / Canada models have different
types of laser light stickers according to local
requirements.
CAUTION! Use of controls or adjustments
or performance of procedures other
than those specified herein may result in
hazardous radiation exposure.
IEC 60825-1:1993+A1:1997+A2:2001
X-ray generator
Nominal power 1750 W nominal at 90 kV, 12.5 mA
Tube voltage 57 - 90 kV (+/- 5 kV)
Tube current 3,2 - 16 mA (+/- 1 mA)
Supply frequency 75 - 150 kHz
Spine compensation kV / mA compensated
Spine compensation mode Pre-programmed
Coefficient of variation of DAP < 5%
Automatic Dose Rate Control
reproducibility
> 95%
NOTICE! Device's radiation dose production vary from unit to unit due to
factory calibration settings. Radiation dose production, shown on the GUI, is
calculated by scaling a measured reference dose production value with the
selected imaging program technical factors and factory calibration setting. Air
KERMA production can be calculated by dividing the provided DAP value with the
active sensor area.
User interface
Program and technical factors
selection, exposure control
Touch screen panel, optional remote exposure
switch
Patient positioning Positioning panel, integrated
Connection cable (Unit - PC) CAT6 UTP Ethernet cable
98 ORTHOPANTOMOGRAPH
™
OP 3D Pro
