3 Advanced use
14 KaVo Scan eXam One
3.1.1 Scanner
3.1.1.1 Status
Shows the scanner type, firmware version and unit
serial number.
3.1.1.2 Image Scanning
If Show Image Preview and Dental Chart is selected
a preview image with a dental chart for tooth
numbering appears before the image is saved.
Using the dental chart
1. After an imaging plate has been processed a
window opens that shows a preview image and
a dental chart.
2. Click the tooth / teeth on the chart that corre-
spond to the tooth / teeth in the image. Tooth
numbers are assigned to the selected teeth.
The tools at the top of the window allow the im-
age to be manipulated.
3. Click OK to save the image and tooth numbers.
Resolution
Super gives a pixel size of 30 μm. This results in
images with better resolution, but may require
longer exposure time to compensate. High
(recommended default) gives a pixel size of 60 μm.
This results in images with less noise especially if
short exposure times are used.
