4 Displaysandoperatingelements
4.1 StatusLEDsoftheaxis
Dependingonthedesignoftheaxismodule(singleaxismodule,double
axismodule,tripleaxismodule)upto3times3LEDsareprovidedasstatus
indicators.TheLEDsareonthefrontofthedeviceandareassignedtoaxis
1toaxis3fromtoptobottom.ThesignificanceoftheLEDsisthesamefor
eachaxisandisasfollows:
Illustration43:StatusLEDs
Axis1(2,3) ...Indicationofwhichaxisis
accessedviathedisplayon
thecontrolmoduleassembly
ERR ...Errorindicationusingflash
ingcode
RUN ...Ready/powerstageactive
