D3DA3xx/x TechnicalData
ProjectengineeringmanualV1.00
91
©KEBA
AtU
mains
=400V
F
S
2kHz 4kHz 8kHz 12kHz 16kHz
Nominalcurrent: 6A 6A 6A 4A 2.9A
Maximumcurrentfor10s: 12A 12A 12A 8A 5.8A
Maximumcurrentfor500ms: 18A 18A 12.5A 9.7A 7.6A
MaximumcurrentatF
M
=0Hz: 14.7A 3A 8A 6.2A 4.8A
AtU
mains
=480V
F
S
2kHz 4kHz 8kHz 12kHz 16kHz
Nominalcurrent: 6A 6A 5.2A 2.7A 1.2A
Maximumcurrentfor10s: 12A 12A 10.4A 5.4A 2.4A
Maximumcurrentfor500ms: 18A 16A 10.4A 7.2A 5.5A
MaximumcurrentatF
M
=0Hz: 12.4A 10.2A 6.6A 4.6A 3.5A
12.2.2 CurrentdataD3DA3x0/x12xx
Information
Currentdataperaxisintheaxismodule400/480VACreferstothefeed
voltageforthesupplymodule.
Appliestoeachproductvariant:
● D3DA310/x12xx:Allvaluesofthefollowingtables
● D3DA320/x12xx:Allvaluesofthefollowingtablesx2
● D3DA330/x12xx:Allvaluesofthefollowingtablesx3
AtU
mains
=400V
F
S
2kHz 4kHz 8kHz 12kHz 16kHz
Nominalcurrent: 12A 12A 10A 6.4A 5.1A
Maximumcurrentfor10s: 24A 24A 20A 12.8A 10.2A
Maximumcurrentfor500ms: 36A 36A 29.3A 19.9A 14.7A
MaximumcurrentatF
M
=0Hz: 36A 29.5A 20.2A 13.7A 10.1A
AtU
mains
=480V
F
S
2kHz 4kHz 8kHz 12kHz 16kHz
Nominalcurrent: 12A 12A 8.7A 5.27A 4A
Maximumcurrentfor10s: 24A 24A 17.4A 10.4A 8A
Maximumcurrentfor500ms: 36A 36A 20.9A 15.5A 12.4A
MaximumcurrentatF
M
=0Hz: 36A 26A 14.4A 15.1A 8.5A
