6 Connectionsandwiring
Information
Complywiththestandardsforelectricalinstallations,suchasregarding
wirecrosssection,PEconductorandearthconnections.
ThefollowinglayoutplanshowsthelayoutoftheD3DA3xx/xaxismodule
withthecorrespondingpositionsofconnectorsandterminals.Toaidorienta
tion,theconnectorsandterminalsarelabelledbyabbreviations(X..).
ThefollowingpagescontaindetailedlayoutdiagramsontheD3DA3xx/x
singleaxis,doubleaxisandtripleaxismodules.
Illustration617:OverviewD3DA3xx/xaxismodules
