D3DA3xx/xMountingandinstallationinstructions
ProjectengineeringmanualV1.00
30
©KEBA
5.2 Spacerequirements
Caution
Theminimumclearanceaboveandbelow(130mmand100mm)statedin
thefigureappliestoalldevices.Theclearanceaboveisimportanttoprevent
thebuildupofheat,theclearanceunderneathtopermitcorrectcablelay
ing.
Illustration57:Mountingclearances
Thebendradiusoftheconnectingcablesmustbetakenintoaccount.
alledimensionsinmm
KeDriveD3example(withcontrolmodulewithsafety
functionalityandwithsupplymodule)
Examplewithoneaxismodulesize1.
