Keithley 6514

SCPI Reference Tables 17-7
Command Description
Default
parameter Ref
SCPI
:ULIMit <NRf> Select autorange upper limit; -0.021 to
0.021 (amps).
2.1e-2
:ULIMit? Query upper limit for autorange.
:LLIMit <NRf> Select autorange lower limit; -0.021 to 0.021
(amps).
2.1e-11
:LLIMit? Query lower limit for autorange.
:AUTO? Query state of autorange. √
:DAMPing <b> Enable or disable current damping. OFF Sec 4
:DAMPing? Query state of damping
:RESistance Path to configure ohms function: √
:NPLCycles <NRf> Set integration rate in line cycles (PLC); 0.01 to
10.
6 (60Hz)
5 (50Hz)
Sec 6 √
:NPLCycles? Query NPLC. √
:RANGe Configure measurement range: Sec 6 √
[:UPPer] <NRf> Select range; 0 to 2.1e11 (ohms). 2.1e5 √
[:UPPer]? Query range value. √
:AUTO <b> Enable or disable autorange. (see Note) √
:ULIMit <NRf> Select autorange upper limit; -2.1e11 to
2.1e11 (ohms).
2.1e11
:ULIMit? Query upper limit for autorange.
:LLIMit <NRf> Select autorange lower limit; -2.1e11 to
2.1e11 (ohms).
2.1e3
:LLIMit? Query lower limit for autorange.
:AUTO? Query state of autorange. √
:GUARd <b> Enable or disable driven guard. OFF Sec 3
:GUARd? Query state of driven guard.
:CHARge Path to configure coulombs function: √
:NPLCycles <NRf> Set integration rate in line cycles (PLC); 0.01 to
10.
6 (60Hz)
5 (50Hz)
Sec 6 √
:NPLCycles? Query NPLC. √
:RANGe Configure measurement range: Sec 6 √
[:UPPer] <NRf> Select range; -21e-6 to 21e-6 (coulombs). 2.1e-6 √
[:UPPer]? Query range value. √
:AUTO <b> Enable or disable autorange. (see Note) √
Table 17-4 (cont.)
SENSe command summary
