Keithley 6514 User Manual

1-6 Getting Started
Shifted
V-DROP Enables/disables V-drop measurements for Ω function.
AUTO-DIS Sets and enables/disables Auto Discharge for charge measurements.
GPIB Configures and enables/disables GPIB interface.
RS-232 Configures and enables/disables RS-232 interface.
Middle Row
Unshifted
AVG Configures and enables/disables digital filter.
MEDN Configures and enables/disables median filter.
REL Enables/disables Relative (Rel).
LIMIT Performs configured limit tests.
DIGIT Sets display resolution.
RATE Selects measurement rate.
 and  Controls cursor position for making selections or editing values.
Shifted
MX+B Configures and enables/disables mX+b math function.
% Configures and enables/disables Percent math function.
VAL Sets Rel value and enables Rel.
CONF-LIM Configures limit tests.
UNITS Selects engineering units for scientific notation for display readings.
NPLC Set rate by setting PLC value.
Bottom Row
Unshifted
STORE Sets the number of readings to store and enables the buffer.
RCLL Displays stored readings (including maximum, minimum, peak-to-peak, average,
and standard deviation). The  and  range keys scroll through the buffer, and the 
or  key toggles between reading number and reading.
DELAY Sets user delay between trigger and measurement.
DAMP Enables/disables damping for current measurements.
HALT Stops measurement process. Puts 6514 in idle state.
TRIG Trigger measurement(s). Takes 6514 out of idle state.
EXIT Cancels selection, moves back to measurement display.
ENTER Accepts selection, moves to next choice or back to measurement display.
Shifted
TEST Performs key-press test or display test.
CAL Accesses calibration.
SAVE Saves present setup to a memory location.
SETUP Restores setup stored in a memory location, or to GPIB or factory defaults.
CONF-ARM Configures Arm Layer of trigger model.
CONF-TRIG Configures Trigger Layer of trigger model.
3 Range keys
 Selects the next higher voltage measurement range.
 Selects the next lower voltage measurement range.
AUTO Enables/disables autorange.
