2400 Series SourceMeter
®
User’s Manual Pulse Mode Operation (Model 2430 only) 5-15
Remote command pulse-measure operation
Basic pulse commands
Table 5-1 summarizes the commands to perform pulse-measure operations. See Section 18
for more information on using these commands.
Ignored settings and invalid commands
When in the Pulse Mode, there are SCPI commands whose settings are ignored, or are
invalid causing error +831 (Invalid in Pulse Mode). The affected commands are covered in
“Pulse-measure considerations,” page 5-16.
Table 5-1
Basic pulse-measure commands
Command Description
:SOURce:FUNCtion:SHAPe PULSe
:SOURce:PULSe:WIDth <n>
:SOURce:PULSe:DELay <n>
:SOURce:FUNCtion <name>
:SOURce:CURRent:MODE FIXed
:SOURce:VOLTage:MODE FIXed
:SOURce:CURRent:RANGe <n>
:SOURce:VOLTage:RANGe <n>
:SOURce:CURRent:LEVel <n>
:SOURce:VOLTage:LEVel <n>
Select Pulse Mode of operation.
Set pulse width in sec (n = 0.00015 to 0.0050).
Set pulse delay in sec (n = 0 to 9999.999).
Select source function (name = VOLTage or CURRent).
Select fixed sourcing mode for I-source.
Select fixed sourcing mode for V-source.
Select I-source range (n = range).
Select V-source range (n = range).
Set I-source amplitude (n = amplitude in amps).
Set V-source amplitude (n = amplitude in volts).
:SENSe:FUNCtion <function>
:SENSe:FUNCtion:OFF:ALL
:SENSe:CURRent:NPLC <n>
:SENSe:VOLTage:NPLC <n>
:SENSe:CURRent:PROTection <n>
:SENSe:VOLTage:PROTection <n>
:SENSe:CURRent:RANGe <n>
:SENSe:VOLTage:RANGe <n>
Select measure function (function = “VOLTage” or “CURRent”).
Disable pulse measurements.
Set pulse measurement speed (n = 0.004 to 0.100).
Set pulse measurement speed (n = 0.004 to 0.100).
Set current compliance (n = compliance).
Set voltage compliance (n = compliance).
Set current measure range (n = range).
Set voltage measure range (n = range).
:ARM:COUNt <n>
:TRIGger:COUNt <n>
Set arm count (n = 1 to 2500 or INFinite).
Set trigger count (n = 1 to 2500).
:READ? Start (trigger) pulse output process and acquire pulse readings.
:INITiate
:ABORt
Start pulse output process (pulse readings not acquired).
Stop pulse output process.
