Source-Measure Concepts
• Compliance limit — Discusses compliance limit including real and range compli-
ances, maximum compliance values, and how to determine compliance limit.
• Overheating protection — Provides information on preventing SourceMeter over-
heating, including power equations.
• Source-delay-measure cycle — Describes the various phases of the source-delay-
measure cycle as well as sweep waveforms.
• Operating boundaries — Covers voltage and current operating boundaries for
source and sink operation, I-source and V-source, and source-measure modes.
• Basic circuit configurations — Covers basic circuit configurations for source I,
source V, and measure only operating modes.
• Guard — Covers cable guard, ohms guard, and guard sense.
• Data flow — Describes measurement readings, math, rel, and limits operation, and
how data is stored in the buffer.
