2400 Series SourceMeter
®
User’s Manual GPIB 488.1 Protocol G-7
Table G-3
SCPI/488.1 reading speed comparisons
for source-measure-limit test sweep operation (rdgs/sec)
Speed NPLC/Trig. origin SCPI 488.1 Improvement
Fast 0.01/internal 809.5 981.1 21.19%
0.01/external 756.2 886.9 17.28%
Medium 0.10/internal 388.9 398.0 2.35%
0.10.external 374.6 383.9 2.47%
Normal 1.00/internal 56.9 57.1 0.41%
1.00/external 56.6 56.9 0.48%
Note: Pass/Fail test performed using one high limit and one low math limit.
Table G-4
SCPI/488.1 reading speed comparisons
for source-memory sweep operation (rdgs/sec)
Speed NPLC/Trig. origin SCPI 488.1 Improvement
Fast 0.01/internal 164.8 165.2 0.23%
0.01/external 162.6 163.0 0.23%
Medium 0.10/internal 132.8 133.0 0.15%
0.10.external 131.4 131.4 0.00%
Normal 1.00/internal 44.4 44.4 0.00%
1.00/external 44.2 44.2 0.00%
Note: Pass/Fail test performed using one high limit and one low math limit.
