2400 Series SourceMeter
®
User’s Manual Limit Testing 12-25
Test parameters for this test include:
• Source Function: current
• Sense Function: voltage
• Source Current: 100mA
• Source Delay: 100ms
• Limit 2 Upper Value: 0.85V
• Limit 2 Lower Value: 0.75V
• Limit 3 Upper Value: 0.82V
• Limit 3 Lower Value: 0.78V
Figure 12-11 demonstrates graphically how parts are sorted. Diodes with a voltage
between 0.78V and 0.82V are considered good and will pass the limits test. Diodes that
test with a slightly wider voltage range are routed to QA for analysis, while those with the
largest voltage tolerance will be discarded.
Figure 12-11
Diode pass/fail limits
Table 12-3 summarizes the basic SCPI command sequence for performing a limit test for
the diode breakdown described above, and Table 12-4 summarizes pass/fail parameters.
Note that the test connections shown in Figure 10-8 can be used for this test.
NOTE Additional programming steps will be necessary to test the values returned by
the :CALC2:LIM2:FAIL? and :CALC:LIM3:FAIL? queries. A returned value of
1 indicated a failure of that limit test.
Bad Diode,
Discard
Bad Diode,
to QA
Good
Diode
Bad Diode,
to QA
Bad Diode,
Discard
Low Limit 2
(0.75V)
Low Limit 3
(0.78V)
Upper Limit 3
(0.82V)
Upper Limit 2
(0.85V)
