18-54 SCPI Command Reference 2400 Series SourceMeter

User’s Manual

Grading mode status bit values:

Result

Bit #: 21 20 19 9 8

Meas. Event

Status

All limits pass 0 0 0 0 0 Bit 5 (LP)

Limit test 1 fail 0 0 0 0 1 Bit 0 (L1)

Hi Limit test 2 fail 1 0 0 1 0 Bit 2 (HL2)

Lo Limit test 2 fail 0 0 0 1 0 Bit 1 (LL2)

Hi Limit test 3 fail 1 0 0 1 1 Bit 4 (HL3)

Lo Limit test 3 fail 0 0 0 1 1 Bit 3 (LL3)

Limit test 4 fail 0 0 1 0 1 Bit 10 (CC)

Hi Limit test 5 fail 1 0 1 0 0 -

Lo Limit test 5 fail 0 0 1 0 0 -

Hi Limit test 6 fail 1 0 1 1 0 -

Lo Limit test 6 fail 0 0 1 1 0 -

Hi Limit test 7 fail 1 0 1 1 1 -

Lo Limit test 7 fail 0 0 1 1 1 -

Hi Limit test 8 fail 1 1 0 0 0 -

Lo Limit test 8 fail 0 1 0 0 0 -

Hi Limit test 9 fail 1 1 0 0 1 -

Lo Limit test 9 fail 0 1 0 0 1 -

Hi Limit test 10 fail 1 1 0 1 0 -

Lo Limit test 10 fail 0 1 0 1 0 -

Hi Limit test 11 fail 1 1 0 1 1 -

Lo Limit test 11 fail 0 1 0 1 1 -

Hi Limit test 12 fail 1 1 1 0 0 -

Lo Limit test 12 fail 0 1 1 0 0 -

1. Limit 4 test available only with contact check option (Appendix F).

2. See Section 15, “Measurement Event Register” and Figure 15-6 for details.
