18-78 SCPI Command Reference 2400 Series SourceMeter
®
User’s Manual
2420
<n> = -3.15 to 3.15 Set I-Source amplitude (amps)
-63 to 63 Set V-Source amplitude (volts)
DEFault 0A or 0V
MINimum -3.15A or -63V
MAXimum +3.15A or +63V
2425 and 2430 DC Mode
<n> = -3.15 to 3.15 Set I-Source amplitude (amps)
-105 to 105 Set V-Source amplitude (volts)
DEFault 0A or 0V
MINimum -3.15A or -105V
MAXimum +3.15A or +105V
2430 Pulse Mode
<n> = -10.5 to 10.5 Set I-Source amplitude (amps)
-105 to 105 Set V-Source amplitude (volts)
DEFault 0A or 0V
MINimum -10.5A or -105V
MAXimum +10.5A or +105V
2440
<n> = -5.25 to 5.25 Set I-Source amplitude (amps)
-42 to 42 Set V-Source amplitude (volts)
DEFault 0A or 0V
MINimum -5.25A or -42V
MAXimum +5.25A or +42V
Query :CURRent? Query programmed amplitude of I-Source
:CURRent? DEFault Query *RST default amplitude
:CURRent? MINimum Query lowest allowable amplitude
:CURRent? MAXimum Query highest allowable amplitude
:VOLTage? Query programmed amplitude of V-Source
:VOLTage? DEFault Query *RST default amplitude
:VOLTage? MINimum Query lowest allowable amplitude
:VOLTage? MAXimum Query highest allowable amplitude
Description This command is used to immediately update the amplitude of a fixed
source. This command is not valid if the list or sweep mode is selected.
NOTE The sourcing :MODE command is used to select a fixed source. (See “Select
sourcing mode,” page 18-74.)
If a manual source range is presently selected, then the specified ampli-
tude cannot exceed that range. For example, if the V-Source is on the 2V
range (auto range disabled), you will not be able to set the V-Source
amplitude to 3V. In auto range, the amplitude can be set to any level that
is within the capabilities of the source.
