2400 Series SourceMeter

User’s Manual IEEE-488 Bus Overview D-15

PP (Parallel Poll Function) — The instrument does not have parallel polling capabilities

(PP0).

DC (Device Clear Function) — DC1 deﬁnes the ability of the instrument to be cleared

(initialized).

DT (Device Trigger Function) — DT1 deﬁnes the ability of the SourceMeter to have

readings triggered.

C (Controller Function) — The instrument does not have controller capabilities (C0).

TE (Extended Talker Function) — The instrument does not have extended talker capa-

bilities (TE0).

LE (Extended Listener Function) — The instrument does not have extended listener

capabilities (LE0).

E (Bus Driver Type) — The instrument has open-collector bus drivers (E1).
