KERN DHS User Manual

DHS Gantry Parts List
NUM.
QTY.
DESCRIPTION
PART NUMBER
NUM.
QTY.
DESCRIPTION
PART NUMBER
1
1
STOP BLOCK
52-1067
47
4
LEG
52-1020
2
1
1/4"-20 x 1.00
91255A542
48
1
MOTOR FACE PLATE
(SERVO)
52-1100
3
1
TAIL NUT BLOCK
52-1042
49
1
X-MOTOR BELT
1066
4
1
BEARING 202
1065
50
1
5:1 GEAR REDUCER
1288
5
2
#10-32 x .750 SHCS
91251A345
51
4
#6-32 x .250 CPCS
91375A144
6
1
GANTRY SUPPORT B
52-1028
52
1
SERVO MOTOR
1276
7
1
TAIL BLOCK
52-1041
53
16
#10-32 x .625 SHCS
91251A344
8
1
#2-56 x .500 SHCS
91251A081
54
8
#10-32 x .500 SHCS
91251A342
9
1
TOP SLIDER
52-1066
55
1
NUT BLOCK
52-1043
10
3
.125" x .250" O.D. 0-RING
1979
56
2
66" RAIL
1247
11
1
MIRROR MOUNT
N-HSE-7
57
16
#6-32 x .750 SHCS
91251A151
12
3
#4-40 x .375 SHCS
91251A108
58
4
LINTECH BEARING
SLBO-8
13
1
1.50" O.D. MIRROR
1582
59
4
BEARING SPACER BLOCK
52-1026
14
1
MIRROR CAP
N-HF-31
60
1
1.900" PULLEY
HF-1091
15
3
#2-56 x .250 PHS
91792A076
61
1
SHAFT NUT
52-1064
16
1
MIRROR COVER
60-1011C
62
4
#10-32 x .375 SHCS
91251A192
17
4
#6-32 x .750 SHCS
91251A151
63
1
BEARING COVER
52-1044
18
2
LASER PLATE SUPPORT
52-1074
64
2
BEARINGS
1064
19
4
#10-32 x 1.00" SHCS
91251A347
65
2
#10-32 x .625 SHCS
91251A344
20
1
SHUTTER RETAINER
52-1062
66
2
#2-56 x .500 SHCS
91251A081
21
1
SHUTTER SWITCH
1133
67
2
#10-32 WASHERS
90126A514
22
1
SHUTTER
52-1065
68
1
LIMIT SWITCH MOUNT
52-1022
23
1
LASER PLATE
52-1069
69
1
LEADSCREW NUT
1240
24
14
1/4"-20 x .625 SHCS
91251A539
70
1
NUT WASER
52-1101
25
10
#10-32 x .625 SHCS
91251A344
71
3
#10-32 x .750 SHCS
91251A345
26
1
SHUTTER BLOCK
N-HSE-12B
72
1
X-AXIS LEADSCREW
52-1006
27
1
UPPER OPTIC TUBE
60-1011B
73
1
LIMIT SWITCH
1070
28
1
ADJUSTABLE NYLON HANDLE
1071
74
4
1/4"-20 x 3.00 SHCS
91251A554
29
1
OPTIC TUBE
HSE-1005
75
1
X-NUT PLATE
52-1039
30
1
MARRIAGE BAR
303-1021
76
2
#10-32 x .625 SHCS
91251A344
31
4
#10-32 x .625 SHCS
91251A344
77
1
GANTRY SUPPORT A
52-1028
33
1
2.50" OPTIC ASSEMBLY
See Optics
Schematic
78
1
TOP GANTRY
52-1017
36
4
#8-32 x 1.500 SHCS
91251A203
79
68
#6-32 x .500 SHCS
91251A148
37
20
#8-32 x .500 SHCS
91251A194
80
2
LEADSCREW WASHER
3088A467
38
1
MOTOR COVER
52-1060
81
1
ROLLTRACK BRACKET A
52-1057
39
2
#10-32 x .375 BHCS
91255A263
82
1
ROLLTRACK BRACKET B
52-1058
40
4
#6-32 x .375 SHCS
91251A146
83
2
#10-32 x .500 SHCS
91251A342
41
1
MOTOR MOUNT B (SERVO)
HF-1026
84
2
1/4"-20 x .500 SHCS
91251A537
42
2
1/4" WASHER
1746
85
1
ROLLTRACK CLAMP
52-1056
43
2
1/4"-20 x .500 SHCS
91251A537
86
1
ROLLTRACK SUPPORT
52-1055
44
2
MOTOR FRAME GUSSET
(SERVO)
52-1095
87
2
1/4"-20 x .625 FHCS
91253A539
45
1
MOTOR MOUNT A (SERVO)
HF-1013
88
2
#4-40 x .500 SHCS
91251A110
46
10
#6-32 x .375 SHCS
91251A146
71
