34 Infiniium Z-Series Oscilloscopes User’s Guide
2 Using the Oscilloscope
A Results pane is visible at the very bottom of the display when you do something
that requires it, such as take a measurement. When it is not needed, the Results
pane is not visible.
Figure 13 Infiniium Oscilloscope Bottom of Display
Expand drag & drop
measurements
Access the Horizontal
Setup dialog box
Set horizontal scale
Set horizontal
position
Zoom on/off
Markers turn on/
set up
Pin/unpin
controls
Figure 14 Results Pane
