Configuration
P/N 06-236716-001 3-7 August 2007
21 Latching for
Supervisory 1
1 — SUPV 1 is non-latching
2 — SUPV 1 is latching (forced if part of Cross-Zone)
1
22 Latching for
Supervisory 2
1 — SUPV 2 is non-latching
2 — SUPV 2 is latching
1
23 Outputs Disabled by
Isolate Button
1 — Disables ARCs
2 — Disables ARCs and NACs
3 — Disables ARCs and Programmable Relays
4 — Disables ARCs, NACs and Programmable Relays
4
24 NAC 1 relationship to
ARCs
1 — ARC 1 only
2 — ARC 2 only
3 — Both ARC 1 and ARC 2 (see note 5)
4 — Neither ARC 1 nor ARC 2 (see note 6)
5 — NAC 1 Not Used (see note 1)
1
25 NAC 2 relationship to
ARCs
1 — ARC 1 only
2 — ARC 2 only
3 — Both ARC 1 and ARC 2 (see note 5)
4 — Neither ARC 1 nor ARC 2 (see note 6)
5 — NAC 2 Not Used (see note 1)
2
26 NAC 3 relationship to
ARCs
1 — ARC 3 only
2 — ARC 3 only
3 — Both ARC 1 and ARC 2 (see note 5)
4 — Neither ARC 1 nor ARC 2 (see note 6)
5 — NAC 3 Not Used (see note 1)
3
27 NAC 1 First Alarm
(see note 8)
0 — 60 bpm Non-Silenceable
1 — 60 bpm Silenceable
2 — 120 bpm Non-Silenceable
3 — 120 bpm Silenceable
4 — Steady Non-Silenceable
5 — Steady Silenceable
6 — Temporal Non-Silenceable
8 — Temporal Silenceable
8 — Intelligent Synchronization - Non-Silenceable
9 — Intelligent Synchronization - Silenceable (Horn &
Strobe)
A — Intelligent Synchronization - Silenceable (Horn Only
Off)
C — NAC 1 Off (see note 7)
1
Table 3-1. Configuration Settings
Configuration
Number
(Position 1, 2)
Configuration Item Configuration (Position 3) Selection
Default
Mode
To Next Page
