Kidde AEGIS 84-732001-001

Configuration
August 2007 3-6 P/N 06-236716-001
14 Automatic Time Delay -
Release Circuit 1
1 — 0 seconds
2 — 10 seconds
3 — 20 seconds
4 — 30 seconds (select for NYC)
5 — 40 seconds
6 — 50 seconds
7 — 60 seconds
7
15 Automatic Time Delay -
Release Circuit 2
1 — 0 seconds
2 — 10 seconds
3 — 20 seconds
4 — 30 seconds (select for NYC)
5 — 40 seconds
6 — 50 seconds
7 — 60 seconds
7
16 On-Time - Release Circuit
1 (see note 4)
1 — Agent Control Head 90 seconds
2 — Deluge Solenoid 10 minutes
3 — Deluge Solenoid 15 minutes
4 — Deluge Solenoid On Until Reset
5 — Initiators
1
17
Power Limited
- Release
Circuit 1 (see note 4)
1 — Power-Limited (one solenoid)
2 — Power-Limited (two solenoids)
3 — Non-Power-Limited (one solenoid)
4 — Non-Power-Limited (two solenoids)
5 — Initiators
3
18 On-Time - Release Circuit
2 (see note 4)
1 — Agent Control Head 90 seconds
2 — Deluge Solenoid 10 minutes
3 — Deluge Solenoid 15 minutes
4 — Deluge Solenoid On Until Reset
5 — Initiators
1
19
Power Limited
- Release
Circuit 2 (see note 4)
1 — Power-Limited (one solenoid)
2 — Power-Limited (two solenoids)
3 — Non-Power-Limited (one solenoid)
4 — Non-Power-Limited (two solenoids)
5 — Initiators
3
20 Trouble Latching 1 — Troubles are non-latching
2 — Troubles are latching (required for cUL)
1
Table 3-1. Configuration Settings
Configuration
Number
(Position 1, 2)
Configuration Item Configuration (Position 3) Selection
Default
Mode
