Kidde AEGIS 84-732001-001

Configuration
P/N 06-236716-001 3-5 August 2007
9 Programmable Relay 2 1 — General alarm (DET 1, DET 2, DET 3/WF, or Manual
Release)
2 — First Alarm (DET 1, DET 2, DET 3/WF, or Manual
Release) (see note 2)
3 — First Alarm (DET 1, DET 2, DET 3/WF, Manual Release,
or SUPV 1) (see notes 2 & 3)
4 — Agent Pre-Release Condition
5 — Agent Release Condition
6 — Manual Release Input
7 — Waterflow Input
8 — Abort Input
9 — Supervisory Input
4
10 Programmable Relay 3 1 — General alarm (DET 1, DET 2, DET 3/WF, or Manual
Release)
2 — First Alarm (DET 1, DET 2, DET 3/WF, or Manual
Release) (see note 2)
3 — First Alarm (DET 1, DET 2, DET 3/WF, Manual Release,
or SUPV 1) (see notes 2 & 3)
4 — Agent Pre-Release Condition
5 — Agent Release Condition
6 — Manual Release Input
7 — Waterflow Input
8 — Abort Input
9 — Supervisory Input
5
11 Trouble Relay 1 — AC Failure response - Instantaneous
2 — AC Failure response - Delayed 1 minute
3 — AC Failure response - Delayed 60 minutes
4 — AC Failure response - Delayed 90 minutes
5 — AC Failure response - Delayed 120 minutes
6 — AC Failure response - Delayed 180 minutes
4
12 Manual Release Station
Time Delay - Release
Circuit 1
1 — Instantaneous (select for NYC)
2 — 10 seconds
3 — 20 seconds
4 — 30 seconds
1
13 Manual Release Station
Time Delay - Release
Circuit 2
1 — Instantaneous (select for NYC)
2 — 10 seconds
3 — 20 seconds
4 — 30 seconds
1
Table 3-1. Configuration Settings
Configuration
Number
(Position 1, 2)
Configuration Item Configuration (Position 3) Selection
Default
Mode
