Chapter 1: Installation and wiring

P/N 3102351-EN • REV 005 • ISS 28DEC18 5

Figure 3: Panel electronics installation

Panel backbox wire routing

Using the diagram below, keep power-limited wiring in the shaded area and nonpower-limited

wiring in the unshaded area at all times.
