Appendix A: Panel specifications
186 P/N 3102351-EN • REV 005 • ISS 28DEC18
Control panel specifications
VS1 panel VS4 panel
1 loop Class B, Class A, or Class X
supporting up to 64 device addresses
(any combination of detectors and
modules)
Maximum T-taps: 63 (each device can
be on its own branch)
1 loop, expandable to 4, Class A, Class
B, or Class X. E
ach loop supporting up to
250 device addresses (125 detectors and
125 modules max.). Addresses 1 to 125
are for detectors and addresses 126 to
250 are for modules.
Maximum T-taps: 124
Notification appliance
circuits
2 Class B, Class A optional
3.75 A FWR total at 120/230 VAC 60 Hz
3.0 A FWR total at 230 VAC 50 Hz
2.5 A FWR each max. per circuit
4 Class B or 2 Class A
6.0 A FWR total at 120/230 VAC
60 Hz
5.0 A FWR total at 230 VAC 50 Hz
2.5 A FWR each max. per circuit
120 VAC, 60 Hz, 1.3 A max.
230 VAC, 50-60 Hz, 0.62 A max.
120 VAC, 60 Hz, 2.0 A max.
230 VAC, 50-60 Hz, 0.97 A max.
Base panel current standby
155 mA 172 mA
panel current alarm 204 mA 267 mA
16 max. 32 max.
8 drops max., RS-485 Class B,
Class A is optional
Data line length: 4,000 ft.
(1,219 m)
8 drops max., RS-485 Class A or B
Data line length: 4,000 ft. (1,219 m)
voltage 24 VDC panel
Auxiliary power output
circuit
AUX 1 power: 500 mA (standby), 24 VDC. Up to 1000 mA of alarm current is
available on AUX 1 if you reduce the total available control panel NACs alarm
current by the amount of AUX 1 + AUX 2 alarm current over 500 mA )
AUX 2 power: 500 mA (standby and alarm), 24 VDC (resettable)
AUX 1 + AUX 2: Total maximum standby current = 500 mA
AUX 1 + AUX 2: Total maximum alarm current = 500 mA; (1000 mA is available if
you reduce the total available control panel NACs alarm current by the amount of
AUX 1 + AUX 2 alarm current over 500 mA)
Output: 28.3 to 21.9 VDC, special application
Note: For a complete list of devices that can be connected to this circuit, see the
VS1 and VS4 Series Compatibility List (P/N 3102354-EN).
