Kidde VS Series User Manual

Chapter 3: System operation
142 P/N 3102351-EN • REV 005 • ISS 28DEC18
Event ID numbers and descriptions
Table 43: Event ID numbers and descriptions
ID
Event description
000
Loop 1 initialization: Loop 1 is starting up
001
Loop 1 fault: A short or open was detected
on loop 1 affecting the communications
between the panel and the devices on the
loop
002
Loop 1 map fault: A mapping fault was
detected on loop 1 while the panel was
mapping the devices
003
Loop 1 card fault: The loop 1 card is not
present or it is not working properly
004
Loop 1 uncfgrd alarm: A device on loop 1
that is not programmed went into alarm
005
Loop 1 uncfgrd trouble: A device on loop 1
that is not programmed went into trouble
006
Loop 1 map mismatch: The loop 1 map in
RAM and the loop 1 map in the database
do not match
007
Loop 1 over limits: There are too many
devices on loop 1
008
Loop 1 device 000: A device on loop 1 has
an address set to zero
009
Loop 1 mapping: Loop 1 is mapping
devices
010
Loop 2 initialization: Loop 2 is starting up
011
Loop 2 fault: A short or open was detected
on loop 2 affecting the communications
between the panel and the devices on the
loop
012
Loop 2 map fault: A mapping fault was
detected on loop 2 while the panel was
mapping the devices
013
Loop 2 card fault: The loop 2 card is not
present or it is not working properly
014
Loop 2 uncfgrd alarm: A device on loop 2
that is not programmed went into alarm
015
Loop 2 uncfgrd trouble: A device on loop 2
that is not programmed went into trouble
ID
Event description
016
Loop 2 map mismatch: The loop 2 map in
RAM and the loop 2 map in the database
do not match
017
Loop 2 over limits: There are too many
devices on loop 2
018
Loop 2 device 000: A device on loop 2 has
an address set to zero
019
Loop 2 mapping: Loop 2 is mapping
devices
020
Loop 3 initialization: Loop 3 is starting up
021
Loop 3 fault: A short or open was detected
on loop 3 affecting the communications
between the panel and the devices on the
loop
022
Loop 3 map fault: A mapping fault was
detected on loop 3 while the panel was
mapping the devices
023
Loop 3 card fault: The loop 3 card is not
present or it is not working properly
024
Loop 3 uncfgrd alarm: A device on loop 3
that is not programmed went into alarm
025
Loop 3 uncfgrd trouble: A device on loop 3
that is not programmed went into trouble
026
Loop 3 map mismatch: The loop 1 map in
RAM and the loop 3 map in the database
do not match
027
Loop 3 over limits: There are too many
devices on loop 3
028
Loop 3 device 000: A device on loop 3 has
an address set to zero
029
Loop 3 mapping: Loop 3 is mapping
devices
030
Loop 4 initialization: Loop 4 is starting up
031
Loop 4 fault: A short or open was detected
on loop 4 affecting the communications
between the panel and the devices on the
loop
