Chapter 3: System operation
P/N 3102351-EN • REV 005 • ISS 28DEC18 143
Event description
Loop 4 map fault: A mapping fault was
detected on loop 4 while the panel was
mapping the devices
Loop 4 card fault: The loop 4 card is not
present or it is not working properly
Loop 4 uncfgrd alarm: A device on loop 4
that is not programmed went into alarm
Loop 4 uncfgrd trouble: A device on loop 4
that is not programmed went into trouble
Loop 4 map mismatch: The loop 4 map in
RAM and the loop 4 map in the database
do not match
Loop 4 over limits: There are too many
devices on loop 4
Loop 4 device 000: A device on loop 4 has
an address set to zero
Loop 4 mapping: Loop 4 is mapping
devices
System startup: The control panel is
starting up
Program mode: The control panel is in
program mode
Reset: The control panel is resetting
Reset/Sil inhibit: Reset/silence inhibit is
activated
Panel silence: The control panel buzzer
was silenced
Signal silence: The control panel NACs
have been silenced
Drill: The control panel is in the drill state
Walk test: The control panel is in the walk
test state
Test fire: A smoke or heat detector is being
tested
Clear history: The control panel’s event
history was cleared
Time: The control panel’s time was
modified
Date: The control panel’s date was
modified
Event description
Common disable: A disable event is taking
place on the control panel
Common trouble: A trouble event is taking
place on the control panel
Ground fault: The panel detected a ground
fault
Battery charger: The panel detected a
battery charger trouble condition. The
charger may not be able to charge the
batteries.
Battery low: The batteries are low on
charge
Battery missing: The battery is no longer
connected
AC power: There is a problem with the
panel’s AC power
Aux. power 1: The control panel detected a
trouble condition on the continuous AUX
power circuit 1
Aux. power 2: The control panel detected a
trouble condition on the resettable AUX
power circuit 2
System AC power: There is a problem with
the panel’s AC power and/or a remote
auxiliary/booster’s AC power
Common alarm: An alarm event is taking
place on the control panel
Common supervisory: A supervisory event
is taking place on the control panel
Common monitor: A monitor event is taking
place on the control panel
Common trouble for telco dialer: A trouble
event, other than a DACT delivery fault is
taking place on the control panel
Common trouble for network dialer: A
trouble event, including a DACT delivery
fault is taking place on the control panel
Outputs Are Latched: Outputs in the system
are in latched condition
Alarm ON: The control panel is in the
manual evacuation state.
