Appendix B: Worksheets
210 P/N 3102351-EN • REV 005 • ISS 28DEC18
Device settings worksheet
The device settings worksheet is used to document the configuration and settings for each of
the devices on the system.
Note: For default settings, see “Factory default settingson page 42.
Type of device Photo detector Photo/heat detector Heat detector
Duct detector Ion detector Relay module
NAC module Input module
Device address
Serial number
Label Line 1
Label Line 2
Zone
Correlation groups
Day sensitivity Normal Least Less More Most
Night sensitivity Normal Least Less More Most
Day prealarm % (Off, 50, 55, 60, 65, 70, 75, 80, 90)
Night prealarm % (Off, 50, 55, 60, 65, 70, 75, 80, 90)
Base type Standard Relay Isolator Sounder
Base follow Alarm Alarm + verify Alarm + prealarm
Head None Riser (sounder bases only)
Follow CO Yes No
Type
Smoke Duct alarm Remote reset
Smoke verified Duct supervisory Remote drill
Smoke heat Monitor Remote signal silence
Smoke CO Supervisory (latching) Remote AC fail
Heat alarm Supervisory (nonlatching) Remote test station
Heat alarm RoR Relay (nonsilenceable) Continuous (nonsilencble)
Pull station Relay (silenceable) Continuous (silenceable)
Waterflow Genesis (silenceable) Alarm
Waterflow (retard) Genesis (nonsilenceable)
